How to Tame your Dragon

This page provides information about configuring various aspects of the Dragon run-time services. Dragon makes every attempt to configure itself to run right out of the box. However, it does need to have Shared Memory configured, especially when Dragon is run in a container or kubernetes cluster.

The following sections describe how various aspects of Dragon can be configured and/or controlled via environment variables. Please read as appropriate for your needs.

Shared Memory 

Dragon runs in either a single-node mode or a multi-node mode. On-node, in single-node or multi-node mode, Dragon uses shared memory to communicate between processes that are co-located with it on the same node. This means that the environment it runs in must be configured to support shared memory. Linux and Mac OS X support shared memory out of the box.

Running inside a container requires a little extra setup. Docker reserves 64K of memory for shared memory by default. That is not enough to run Dragon. Dragon requires around 6GB of shared memory be configured. Depending on its workload it may use much less, but Dragon certainly uses more than 64K. Don’t worry, you can reserve more than you need. Unless Dragon actually uses all of what you reserve, the memory of your node is still available for other things. Reservation of shared memory simply means it is allowed to grow to a specific size, not that it necessarily will.

When a Docker container is started, you specify the amount of shared memory it should get with a flag for the amount of shared memory reserved. We have an example of our single-node Dockerfile in our repo which can be found here. If you are running the docker command outside of VSCode or some other application, if you run the docker command using the --shm-size argument you can specify the amount of shared memory.

docker run -p 8888:8888 -it --shm-size=6g --ulimit core=-1 --rm quay.io/jupyter/datascience-notebook:lab-4.4.9 /bin/bash

If you should forget (or not know) to set the shared memory size for a container, Dragon will notify you of that and will tell you to set the amount of shared memory to something reasonable. Dragon looks at the amount of available shared memory when creating a managed memory pool and if there is insufficient space left when the pool is created, then it will notify you of that and refuse to create it. This is a slightly odd check, but it means you can create pools that together are bigger than the amount of reserved shared memory as long as you don’t fill them. This check exists to prevent Dragon from taking a core dump if the amount of shared memory is way too small. It also is useful to know before a long run that you may need more shared memory allocated to complete the run so this check is a best attempt at sharing that information with you up front.

While Dragon is running, the amount of available shared memory on each node is also monitored and if it gets to a warning level, text will appear on the console to warn the user of what is happening and it it gets critical, then the run-time may be taken down with an appropriate error message to say what is happening.

The up front check of available shared memory when a pool is created, in some situations, might become a nuisance and not helpful. If that were the case, then it might be best to disable the up front check. This can be done by setting an environment variable to turn it off.

export DRAGON_CHECK_SHM_FREE_SPACE=false

Setting this environment variable will turn off the check of available free space when a managed memory pool is created. It will not turn off the monitoring of available free shared memory while the application is running. That can be controlled as described in Monitoring Node Memory.

Memory Pool Sizes 

When the Dragon run-time starts, it creates two managed memory pools on every node. The default pool is where user data, like the contents of queues, connections, and Dragon data structures, is allocated. The infrastructure pool is reserved for messages exchanged by the Dragon services themselves.

The size of the default pool is controlled by DRAGON_DEFAULT_SEG_SZ and the size of the infrastructure pool is controlled by DRAGON_INF_SEG_SZ. Both are set to a number of bytes and must be positive. By default the pool sizes are 4GB (i.e. 2³² bytes) and 1GB (i.e. 2³⁰ bytes) respectively.

# Give the default pool 16GB on each node.
export DRAGON_DEFAULT_SEG_SZ=17179869184

If your application stores a lot of data in Dragon objects, for instance in a distributed dictionary or in large messages sent between processes, and you see out of memory errors coming from the default pool, then increasing DRAGON_DEFAULT_SEG_SZ is the first thing to try. Remember that these pools live in shared memory, so the size you request must fit within the shared memory that is configured on the node. See Shared Memory for how to reserve more shared memory when running in a container.

The infrastructure pool rarely needs to be changed. It only holds infrastructure messages, so it does not grow with the size of your data.

Monitoring Node Memory 

While your application is running, Dragon monitors the amount of free memory on each node. If free memory gets low, a warning is written to stderr. If it gets critically low, Dragon will bring the run-time down with a message rather than letting the application deadlock while waiting for memory that will never become available.

Both the warning and the critical threshold can be expressed either as a percentage of free memory or as a number of free bytes. Dragon computes both and uses whichever threshold triggers at the lower number of available bytes. That way a single default works reasonably well for both small and large nodes.

The four environment variables that control these thresholds are:

DRAGON_MEMORY_WARNING_PCT - The percentage of free memory, between 0 and 100, at which a warning is printed. It defaults to 10. Setting it to 100 means the percentage is never the deciding factor, so the byte threshold is used instead.
DRAGON_MEMORY_WARNING_BYTES - The number of free bytes at which a warning is printed. It defaults to 6GB. Setting it to 0 means the byte count is never the deciding factor, so the percentage is used instead.
DRAGON_MEMORY_CRITICAL_PCT - The percentage of free memory, between 0 and 100, at which the run-time is taken down. It defaults to 2. Setting it to 100 means the percentage is never the deciding factor.
DRAGON_MEMORY_CRITICAL_BYTES - The number of free bytes at which the run-time is taken down. It defaults to 600MB. Setting it to 0 means the byte count is never the deciding factor.

For example, to warn once a node drops below 20 percent free memory and to rely only on the percentage rather than a byte count, you could use:

export DRAGON_MEMORY_WARNING_PCT=20
export DRAGON_MEMORY_WARNING_BYTES=0

Setting both the percent to 100 and the bytes to 0 for the critical threshold disables critical out of memory handling entirely. Be aware that doing so means an out of memory condition will likely show up as a hang that your program has to detect and deal with on its own.

If you would rather not see the warnings at all, but still want the critical takedown to protect you from a hang, set DRAGON_WARNINGS_OFF to any value other than False.

export DRAGON_WARNINGS_OFF=True

Warnings are printed by default. Even with warnings suppressed, a critical out of memory condition still prints its message and brings the run-time down.

Wait Modes 

Whenever a process waits on a Dragon object, for instance receiving from a queue or a connection, it does so using one of three wait modes.

IDLE_WAIT - The process sleeps until it is notified. This uses almost no CPU while waiting, but it has a higher latency when the wait is satisfied.
SPIN_WAIT - The process busy waits. This gives the lowest latency, but it consumes a core for the entire time it is waiting.
ADAPTIVE_WAIT - The process spins for a short time and then falls back to idle waiting. This gets much of the low latency of spin waiting without burning a core when the wait turns out to be a long one.

There are two environment variables that select the wait mode. DRAGON_USER_WAIT_MODE applies to the objects your program creates and defaults to ADAPTIVE_WAIT. DRAGON_INF_WAIT_MODE applies to objects created internally by the Dragon services and defaults to IDLE_WAIT.

export DRAGON_USER_WAIT_MODE=SPIN_WAIT

Choosing SPIN_WAIT makes sense when you are latency sensitive and have cores to spare. Choosing IDLE_WAIT makes sense when you are oversubscribing cores and would rather not have waiting processes competing with working ones. Unless you are debugging the run-time itself, there is generally no reason to change DRAGON_INF_WAIT_MODE.

Send Return Modes 

When a process sends a message, Dragon can return control to the sender at several different points in the delivery of that message. The choice trades asynchrony against the guarantees the sender gets when the send completes.

WHEN_IMMEDIATE - Return as soon as the send is initiated. This is the most asynchronous option, but it does not guarantee ordering with respect to other operations on the destination channel.
WHEN_BUFFERED - Return once the message has been buffered and the sender’s copy of the data may be reused.
WHEN_DEPOSITED - Return once the message has been deposited into the destination channel.
WHEN_RECEIVED - Return once the message has been received by the receiver. This is the strongest guarantee and the least asynchronous.

As with wait modes, there are two environment variables. DRAGON_USER_RETURN_WHEN_MODE applies to the objects your program creates and defaults to WHEN_DEPOSITED. DRAGON_INF_RETURN_WHEN_MODE applies to objects created by the Dragon services and defaults to WHEN_BUFFERED.

export DRAGON_USER_RETURN_WHEN_MODE=WHEN_BUFFERED

Relaxing the user return mode to WHEN_BUFFERED can improve throughput for applications that send many messages, so long as your application does not depend on a message having landed in the destination when the send call returns.

Gateway Channel Capacity 

On multi-node runs, off-node operations are routed through gateway channels that the transport agent services. Each gateway channel holds a fixed number of pending requests, and that number is set by DRAGON_GW_CAPACITY. It must be a positive integer and it defaults to 2048.

export DRAGON_GW_CAPACITY=8192

If your application floods the run-time with off-node operations, the gateway channel may fill up and processes will block waiting for room in it. Raising the capacity gives the transport agent more room to absorb bursts, at the cost of some additional memory in the default pool on each node. This variable has no effect on single-node runs.

Optional GPU Library Configuration 

If your nodes do not have GPUs, you can skip this section. GPU library configuration only matters when Dragon needs to detect and use GPUs on single or multi-node systems.

Dragon supports CUDA, HIP, and ZE (Intel Level Zero) GPU backends. To detect GPUs, Dragon dynamically opens the vendor’s runtime library at runtime. By default, Dragon looks for the following libraries:

libcudart.so for CUDA,
libamdhip64.so for HIP, and
libze_intel_gpu.so.1 for ZE.

If the appropriate GPU drivers and libraries are installed on all nodes and can be found through the ld cache or a library path environment variable such as LD_LIBRARY_PATH, no configuration is required. Otherwise, use dragon-config to tell Dragon where to find the library. There are two options for each vendor that can be used separately or together.

The --<vendor>-runtime-lib option provides a directory that contains the runtime library:

dragon-config add --cuda-runtime-lib=/opt/cuda/lib64
dragon-config add --hip-runtime-lib=/opt/rocm/lib
dragon-config add --ze-runtime-lib=/opt/intel/oneapi/level-zero/latest/lib

The --<vendor>-runtime-libname option overrides the default library name. It accepts either a bare library name or a full path to the library. This is useful when the system only provides a versioned library, such as libcudart.so.12, rather than the unversioned default:

dragon-config add --cuda-runtime-libname=libcudart.so.12
dragon-config add --cuda-runtime-libname=/usr/lib64/libcudart.so.12
dragon-config add --hip-runtime-libname=libamdhip64.so.6
dragon-config add --ze-runtime-libname=libze_intel_gpu.so.1

Using these settings, Dragon locates the GPU runtime library by trying each of the following, in order, and using the first one that is found:

The name or full path given by --<vendor>-runtime-libname, as-is, if set.
If --<vendor>-runtime-libname is a full path, its bare library name via the ld cache or a library path environment variable (e.g. LD_LIBRARY_PATH).
The bare library name from --<vendor>-runtime-libname joined with the --<vendor>-runtime-lib directory, if both are set.
The default library name joined with the --<vendor>-runtime-lib directory, if set.
The default library name via the ld cache or a library path environment variable.

For example, with the following configuration:

dragon-config add --cuda-runtime-lib=/opt/cuda/lib64
dragon-config add --cuda-runtime-libname=libcudart.so.12

Dragon tries libcudart.so.12 through the normal library search path, then /opt/cuda/lib64/libcudart.so.12, then /opt/cuda/lib64/libcudart.so, and finally libcudart.so through the normal library search path.

For help without referring to this documentation, you can always use dragon-config --help and dragon-config add --help.

Optional Multi-Node Transport Configuration 

If you are running on a single node, you can skip this section. Transport-agent configuration matters when Dragon needs to communicate across compute nodes.

On multi-node systems it is necessary to configure Dragon to handle off-node communication, which Dragon does automatically through a transport agent. If running Dragon single-node, no transport agent configuration is required.

Dragon includes two separate transport agents for communication across compute nodes. The “TCP transport agent” provides TCP communication between nodes over the interconnection network. The TCP transport is the lower performing of the two agents, but still useful for many applications.

Dragon also includes a “High Speed Transport Agent (HSTA)”, which supports UCX for Infiniband networks and OpenFabrics Interface (OFI) for HPE Slingshot and RoCE RDMA. However, Dragon can only use these networks if its environment is properly configured.

To configure the transport agent run dragon-config with the appropriate arguments. While Dragon will fall back to the TCP agent, if dragon-config is not run, an annoying message about configuring the transport agent will be displayed.

To configure HSTA, use dragon-config to provide an “ofi-runtime-lib” or “ucx-runtime-lib”. The input should be a library path that contains a libfabric.so for OFI or a libucp.so for UCX. These libraries are dynamically opened by HSTA at runtime.

Some example high-speed transport agent configuration commands are:

# For UCX communication, provide a library path that contains a libucp.so:
dragon-config add --ucx-runtime-lib=/opt/nvidia/hpc_sdk/Linux_x86_64/23.11/comm_libs/12.3/hpcx/hpcx-2.16/ucx/prof/lib

# For OFI communication, provide a library path that contains a libfabric.so:
dragon-config add --ofi-runtime-lib=/opt/cray/libfabric/1.22.0/lib64

As mentioned, if dragon-config is not run to tell Dragon where the appropriate libraries exist, Dragon will fall back to using the TCP transport agent. You’ll know this because a message similar to the following will print:

By default Dragon looks for a configuration file to determine which transport
agent implementation to use. However, no such configuration file was found.
Please refer to `dragon-config --help`, DragonHPC documentation, and README.md
to determine the best way to configure the transport agent for your
compute environment. In the meantime, Dragon will use the TCP transport agent
for network communication. To eliminate this message and continue to use
the TCP transport agent, run:

    dragon-config add --tcp-runtime=True

If you get tired of seeing this message and plan to only use TCP communication over ethernet, follow the directions above and run the dragon-config command to silence it with:

dragon-config add --tcp-runtime=True

For help without referring to this README.md, you can always use dragon-config --help.

Tuning the High Speed Transport Agent 

Two environment variables control how much memory HSTA dedicates to buffering data. Both are given in megabytes and both must be positive.

DRAGON_HSTA_MAX_EJECTION_MB sets the size of the buffers used for network receive operations, which is what limits the rate at which HSTA ejects data from the network. It defaults to 64.

DRAGON_HSTA_MAX_GETMSG_MB sets the size of the buffers used for local getmsg operations, which limits the rate at which memory is consumed for messages using the GETMSG protocol. It defaults to 8.

export DRAGON_HSTA_MAX_EJECTION_MB=128
export DRAGON_HSTA_MAX_GETMSG_MB=16

Raising these values can improve bandwidth for applications that move a lot of large messages between nodes, but it also increases the memory HSTA holds on each node. These variables only apply when HSTA is in use, so they have no effect if you are running with the TCP transport agent.

Overlay Network 

In addition to the transport agent that carries your application’s data, Dragon brings up an overlay network that connects the launcher frontend to the backend on each compute node. The overlay network is used for bring-up, teardown, logging and other infrastructure traffic.

DRAGON_OVERLAY_TRANSPORT selects the transport agent used for the overlay network. It can be set to tcp or hsta and it defaults to tcp. This is normally set for you by the launcher, and the --overlay-transport command line option to dragon takes precedence over it.

export DRAGON_OVERLAY_TRANSPORT=tcp

DRAGON_OVERLAY_FANOUT controls the shape of the tree the frontend uses to reach the backend nodes over the overlay network. It is the number of children each node in that tree has, it must be a positive integer, and it defaults to 32.

export DRAGON_OVERLAY_FANOUT=64

A larger fanout makes the tree shallower, which reduces the number of hops messages take, but it also means more direct connections per node. On very large allocations, adjusting the fanout can affect how quickly the run-time starts up and shuts down.

Network Configuration Caching 

Before a multi-node run can start, Dragon must discover the network configuration of each node in the allocation. To avoid repeating that work for every run in the same allocation, each node caches its own network configuration in a file in the system temporary directory.

DRAGON_NET_CONF_CACHE_TIMEOUT is the number of seconds a cached network configuration is considered valid. It defaults to 3600, that is, one hour. A cached configuration older than this is discarded and the configuration is gathered again.

# Only trust cached network configuration for five minutes.
export DRAGON_NET_CONF_CACHE_TIMEOUT=300

Setting the timeout to 0 effectively disables the use of the cache, since any cached entry will immediately be considered stale.

DRAGON_NET_CONF_CACHE_SALT is a string appended to the name of the cache file. The launcher generates a random salt for each run-time and places it in the environment so that two Dragon run-times sharing a node do not read each other’s cached configuration. You generally do not need to set this yourself, but setting it lets you deliberately share, or deliberately isolate, a cache across runs.

The multiprocessing Pool Implementation 

Dragon provides two implementations of multiprocessing.Pool, and DRAGON_BASEPOOL selects which one is used. It must be set to either NATIVE or PATCHED and it defaults to NATIVE.

NATIVE is the Dragon native implementation of the pool. PATCHED is the standard Python multiprocessing pool with Dragon’s objects underneath it and a patched terminate_pool method.

export DRAGON_BASEPOOL=PATCHED

The native pool is the better performing of the two and is the right choice for almost all applications. Selecting PATCHED is worth trying if you are porting an existing multiprocessing application that depends on some behavior of the standard pool that the native pool does not reproduce.
